Economics type plate edge milling machine, feed speed 0~1500mm/min, can be process corbon steel

GMMA-60S Protable edge milling machine technical parameters

Power Supply：AC 380V  50HZ

Total Power：4520W

Feed Speed：0~1500mm/min（According to bevel depth and material）

Clamp Thickness：6~60mm

Clamp Width：＞80mm (Not processing edge)

Processing Length：＞300mm

Bevel Angle：0°~60°Adjustable

Single Bevel Width：0~20mm （Change according to material and angle）

Bevel Width：0~45mm（Change according to bevel angle）

Cutter Plate：φ63 mm

Cutter Qty：6pcs

Worktable Height：700~760mm

Travel Space：800*800mm

Net Weight：200kg

Gross Weight：255kg

Package Size：800*690*1140mm
