Plate Table Edge Milling Machine bevel angle: 25~80degrees, clam thickness:3~30mm

GMMA-20T Edge milling machine technical parameters

Power Supply：AC380V 50HZ

Total Power：1620W

Spindle Speed：2000r/min

Feed Speed：0~1000mm/min（According to bevel depth and material）

Clamp Thickness：3~30mm

Clamp Width：＞20mm (Not processing edge)

Processing Length：＞100mm

Bevel Angle：25°~80°Adjustable

Single Bevel Width：0~12mm（According to bevel angle and material）

Bevel Width：0~25mm （According to bevel angle）

Cutter Plate：φ80 mm

Cutter Qty：9pcs

Worktable Height：580mm

Worktable Size：450*100mm

Net Weight：155kg

Gross Weight：185kg

Package Size：660*600*1100mm
